MTP MPO CASSETTES for Plug N Play

Offering a wide range of MTP/MPO products including single mode or multimode MPO and MTP Cassettes.  The standard cassettes can accommodate 12 and 24 port configurations.  Available in all Fiber types and All connector options.  We use US Conec products for our MTP Solutions


MTP Cassette  options include:


MTP connectors options:
     8-Fiber, Multimode MTP Cassette
     8-Fiber, Single-mode APC MTP Cassette
     8-Fiber, SM MT Elite® Single-mode APC MTP Cassette
    12-Fiber, Multimode MTP Cassette
    12-Fiber, MM MT Elite®, Multimode MTP Cassette
    12-Fiber, Single-mode APC MTP Cassette
    12-Fiber, MT Elite® Single-mode APC MTP Cassette
     24-Fiber, Multimode MTP Cassette
     24-Fiber, MM MT Elite®, Multimode MTP Cassette
     For 24 Fiber Cassette the option of 1)24 fiber MTP connector or 2) 12 Fiber



Connectors
MTP connector gender:
      Male (with pins)
      Female (no pins)

Flowchart: Alternate Process: Text Box: 12
Text Box: MTC
Text Box: LC
Text Box: K
Text Box: 1
Text Box: 7
Text Box: L
Flowchart: Alternate Process: Flowchart: Alternate Process: Flowchart: Alternate Process: Text Box: Example Part Number   MTC-12LCK179

12 Fiber MPO/MTP Fiber Optic Cassette,  Multimode 50/125um OM3 10Gb.  Front of Cassette has 12 LC ports,  Rear of cassette has (1) 12 Fiber MTP Male (with guide pins).

-

Number of Connectors in Rear

Front Connector Type

Fiber Count

Product Group

Flowchart: Alternate Process:

Fiber Mode

Flowchart: Alternate Process:

Rear Connector Type

Flowchart: Alternate Process:

Cassette Box Type

Cassette HoldersMTP Cassette OptionsFiber Optic Cables

Toll Free (877)-320-3143

Call  (321)-473-8933

For Fiber Optic Cables and a fiber optic distribution companyUSA manufactured Fiber Optic CablesRoHS Compliant Fiber Optic CablesFiber Optic Cables
FibertronicsFiber Optic GSA Contract supplierFlowchart: Alternate Process: Fiber Optic Cables



MTP/MPO 12 Fiber Assembly Examples

Fiber Mode

Front Connector

PART#

PRICE

MTP Multimode 12 Fiber MPO Cassette,  With LC/UPC

Connector Type:  12f MTP Standard  Male

Polish Type:  UPC Flat polish

Multimode 50/125µm Fiber

12 LC/UPC

MTC-12LCK17L

$149.95

MTP Multimode 24 Fiber MPO Cassette,  With LC/UPC

Connector Type:  (2) 12f MTP Standard  Male

Polish Type:  UPC Flat polish

Multimode 50/125µm Fiber

24 LC/UPC

MTC-24LCK17L

$229.00

MTP Singlemode 12 Fiber MPO Cassette,  With LC/UPC

Connector Type:  12f MTP/APC Standard  Male

Polish Type:  UPC Flat polish

Singlemode 9/125µm Fiber

12 LC/UPC

MTC-12LCG19L

$169.95

MTP Singlemode 24 Fiber MPO Cassette,  With LC/UPC

Connector Type:  (2) 12f MTP/APC Standard  Male

Polish Type:  UPC Flat polish

Singlemode 9/125µm Fiber

24 LC/UPC

MTC-24LCG19L

$239.95



Cassette Box Type

L

LGX Mounting Pins

N

Narrow Alternate Pins

G

24 Fiber MTP Pin 1 to Pin13





Cassette Fiber Count

6

6 Fiber MPO/MTP Cassette

8

8 Fiber MPO/MTP Cassette

12

12 Fiber MPO/MTP Cassette

16

16 Fiber MPO/MTP Cassette (LC Only)

24

24 Fiber MPO/MTP Cassette (LC Only)

C

Special, Customer Requested.

Fiber Mode

9

9/125 Singlemode

6

62.5/125 Multimode

7

50/125 Multimode 10Gb OM3

4

50/125 Multimode 10Gb OM4

Rear Connector

A

8 Fiber MTP/APC Male (pins)

B

8 Fiber MTP/APC Female

C

8 Fiber MTP/UPC Male (pins)

D

8 Fiber MTP/UPC Female

E

12 Fiber MTP/APC Elite Male (pins)

F

12 Fiber MTP/APC Elite Female

G

12 Fiber MTP/APC Std. Male (pins)

H

12 Fiber MTP/APC Std. Female

I

12 Fiber MTP/UPC Elite Male (pins)

J

12 Fiber MTP/UPC Elite Female

K

12 Fiber MTP/UPC Std. Male (pins)

L

12 Fiber MTP/UPC Std. Female

M

24 Fiber MTP/APC Std. Male (pins)

N

24 Fiber MTP/APC Std. Female

O

24 Fiber MTP/UPC Std. Male (pins)

P

24 Fiber MTP/UPC Std. Female





Front Connector

SC

SC/UPC

SCA

SC/APC

FC

FC/UPC

FCA

FC/APC

LC

LC/UPC

LCA

LC/APC

ST

ST/UPC





Rack Mount MTP Cassette Holder

PART#

LENGTH

PRICE

PP1UCASS

1U Rack mount MPO cassette holder for LGX type cassettes

$89.50

PP1UCASSPO

1U Rack mount MPO cassette holder Pull-out type, for LGX type cassettes

$115.00

PP4UCASS

4U Rack mount vertical MPO cassette holder for LGX type cassettes

$225.00
