D38999 Fiber Optic Cable Assemblies

Flowchart: Alternate Process: D38999 Wall Mount ConnectorD38999 Plug Connector

We offer custom fiber optic cable assemblies using only the highest quality materials.
The MIL-DTL-38999 connector is a harsh environment connector used primarily for fiber optic and electric interconnect applications in aerospace, high-tech missile communication, and other applications requiring high reliability. It is built with excellent EMI screening performance to perfectly interrupt electromagnetic wave interruption. This connector establishes an exact signal line without external interference.



The D38999 assemblies are available in 3 modes

· D38999 Fiber Optic Cable Assemblies

· D38999 Hybrid Assemblies (Multimode and Single mode)

· D38999 Composite Assemblies (Fiber Optic and Electric)



Connector Manufacturers used for our 38999 cable assemblies

· Delphi Connection Systems MIL-DTL-38999 Connectors

· Amphenol (Fiber systems International)

· Glenair Connectors and backshells



Features

· Available in 2, 4, 5, 8, 11, 16, 21, 29, 37 channel configurations

· Utilizes field proven M29504/04, M29504/05 termini

· Single mode and multimode capable

· In-line and wall mount receptacles

· Fully environmentally sealed

· Field maintainable

· Point-to-point interconnect system

· Qualified to MIL-DTL-38999 specifications (commercial equivalent available)



Performance Characteristics .

· Optical insertion loss:

·                  9/125 SM fiber: 0.25 dB avg.

·                  62.5/125 MM fiber: 0.6 dB avg.

· Operating temperature: -65°C to +150°C

· Vibration: per TIA/EIA-455-11, Condition II & VII

· Shock: MIL-S-901, GR.A, CL.1, high impact

· Mating durability: 500 cycles



Fiber Optic Cable Assembly common types:

· 38999 Breakout, Fan-out assemblies

· 38999 MQJ (Measurement Quality Jumper) For testing and certifying assemblies

· 38999 Hybrid Cable assemblies, with both Single mode and Multimode in the same cable

· 38999 Composite assemblies, with both fiber optic and electrical in the same assembly

· Single Mode 9/125µm M29504/04 or M29504/05 Mil Termini, with either Pins or Sockets

· Multimode 62.5/125µm M29504 or M29504/05 Mil Termini, with either Pins or Sockets

· Multimode 50/125µm M29504 or M29504/05 Mil Termini, with either Pins or Sockets



Fiber Optic Cables

Toll Free (877)-320-3143

Call  (321)-473-8933

For Fiber Optic Cables and a fiber optic distribution companyUSA manufactured Fiber Optic CablesRoHS Compliant Fiber Optic CablesFiber Optic Cables
FibertronicsFiber Optic GSA Contract supplierFlowchart: Alternate Process: Fiber Optic Cables





MIL-DTL-38999

2, 4, 5, 8, 11, 16, 21, 29, and 37 channel configurations

Singlemode, Multimode 62.5/125, Multimode 50/125

Hybrid (Multimode and Singlemode) and Composite (Electro-optical)

Jam Nut, Wall Mount, or Plug

Various Shell / Plating Options

EMI Screening for Electromagnetic Wave Interruption
