FC/APC Fiber Optic Attenuator



We manufacture and stock a large supply of FC/APC fiber optic attenuators.  Available in SM singlemode 9/125, MM multimode 62.5/125um and 50um types.  These are a male to female build out fiber attenuator.  Additional options for inline attenuators and bulkhead type.
 Corning Fiber Optic Cable, or doped fiber attenuation.

Call us today to speak with one of our qualified sales people to help answer any questions.

Flowchart: Alternate Process: Text Box: I
Text Box: ILFA
Text Box: I
Text Box: 9
Text Box: S
Text Box: 3
Text Box: Y
Text Box: R
Text Box: 01
Flowchart: Alternate Process: Flowchart: Alternate Process: Flowchart: Alternate Process: Flowchart: Alternate Process: Flowchart: Alternate Process: Flowchart: Alternate Process: Flowchart: Alternate Process: Text Box: M
Flowchart: Alternate Process: Flowchart: Alternate Process: Flowchart: Alternate Process: Flowchart: Alternate Process: Flowchart: Alternate Process: Flowchart: Alternate Process: Flowchart: Alternate Process: Flowchart: Alternate Process: Flowchart: Alternate Process:

Example Part Number   ILFA-II9S3YR01M5

FC/APC to FC/APC In-Line Fiber Optic Attenuator, Single Mode 9/125µm Simplex with a 3mm Yellow Riser Jacket 1 Meter Long, 5dB loss

-

Jacket Color



Y= Yellow

0(zero)= Orange

A= Aqua

L= Blue

G= Green

E= Brown

S= Slate

W= White

R= Red

B= Black

U= Purple

P= Pink

Cable

Diameter



3= 3mm Jacket

2= 2mm Jacket

4= 900µm (.9mm)

6= 250µm Bare

7= 500µm Bare

Fiber Mode



9= 9/125µm Single mode

6= 62.5/125µm Multimode

7= 50/125µm Multimode

4= 50/125µm OM4



Connector B



D= SC/UPC

E= SC/APC

F= E2000

G= E2000/APC

H= FC/UPC

I=  FC/APC

K= LC/UPC

L= LC/APC

S= ST/UPC

Y=MT-RJ

Connector A



D= SC/UPC

E= SC/APC

F= E2000

G= E2000/APC

H= FC/UPC

I=  FC/APC

K= LC/UPC

L= LC/APC

S= ST/UPC

Y=MT-RJ

UOM



Unit Of Measurement

M= Meters

F= Feet

I= Inches

C= Centimeters

Jacket Type



R= Riser (OFNR)

P= Plenum (OFNP)

L= Low Smoke Zero Halogen (LSZH)

N= None

V= PVC Jacket

See Jacket Diameter

Fiber Count



S = Simplex (1 Fiber)

See UOM

Length



Total Cable Length

See Jacket Type

See Jacket Color

Product Group

See Connector A

See Connector B

See Fiber Mode

Text Box: 5
Flowchart: Alternate Process:

Attenuation

FC/APC Attenuator 1-25dBFiber Optic Cables

Toll Free (877)-320-3143

Call  (321)-473-8933

For Fiber Optic Cables and a fiber optic distribution companyUSA manufactured Fiber Optic CablesRoHS Compliant Fiber Optic CablesFiber Optic Cables
FibertronicsFiber Optic GSA Contract supplierFlowchart: Alternate Process: Fiber Optic Cables

FC/APC Singlemode Attenuators





Size

Wave Length Measured at

Part#

Price



FC/APC Male to Female build out single mode fiber attenuator

1dB

1310nm and 1550nm

DFA732011

$17.95

FC/APC Male to Female build out single mode fiber attenuator

2dB

1310nm and 1550nm

DFA732021

$17.95

FC/APC Male to Female build out single mode fiber attenuator

3dB

1310nm and 1550nm

DFA732031

$17.95

FC/APC Male to Female build out single mode fiber attenuator

4dB

1310nm and 1550nm

DFA732041

$17.95

FC/APC Male to Female build out single mode fiber attenuator

5dB

1310nm and 1550nm

DFA732051

$17.95

FC/APC Male to Female build out single mode fiber attenuator

6dB

1310nm and 1550nm

DFA732061

$17.95

FC/APC Male to Female build out single mode fiber attenuator

7dB

1310nm and 1550nm

DFA732071

$17.95

FC/APC Male to Female build out single mode fiber attenuator

8dB

1310nm and 1550nm

DFA732081

$17.95

FC/APC Male to Female build out single mode fiber attenuator

9dB

1310nm and 1550nm

DFA732091

$17.95

FC/APC Male to Female build out single mode fiber attenuator

10dB

1310nm and 1550nm

DFA732101

$17.95

FC/APC Male to Female build out single mode fiber attenuator

12dB

1310nm and 1550nm

DFA732121

$17.95

FC/APC Male to Female build out single mode fiber attenuator

15dB

1310nm and 1550nm

DFA732151

$17.95

FC/APC Male to Female build out single mode fiber attenuator

20dB

1310nm and 1550nm

DFA732201

$17.95

FC/APC Male to Female build out single mode fiber attenuator

25dB

1310nm and 1550nm

DFA732251

$17.95

In-Line Fixed Fiber Optic Attenuator Cables



In-Line fixed attenuators are available in various lengths and connector types.  The are built by customer order so the operating wavelength must be stated when ordered.  Available in 5, 10,15 and 20 dB levels.  Priced by final length. Call for quote.
