M28876 Fiber Optic Cable Assemblies

Flowchart: Alternate Process: 4 channel M28876 Fiber Optic Cable Assembly31 Channel M28876 Fiber Optic Cable Assembly.

We offer custom fiber optic cable assemblies using only the highest quality materials.
The MIL-C-28876 connector is a harsh environment connector primarily used for fiber optic interconnect applications in shipboard applications by navies around the world.



The M28876 assemblies are available in 3 connectors types

· M28876 Wall Mount Receptacle

· M28876 Plug

· M28876 Jam Nut Receptacle



Connector Manufacturers used for our Mil cable assemblies

· Delphi Connection Systems MIL-PRF-28876 Connectors

· Amphenol (Fiber Systems International)



Features

· Channel Configurations: 2, 4, 6, 8, 18 and 31

· Shell sizes: 11, 13, 15 and 23

· Utilizes field-proven M29504 termini

· Singlemode and multimode capable

· In-line and wall mount receptacles

· Fully environmentally sealed

· Field maintainable

· Point-to-point interconnect system

· Qualified to MIL-C-28876 specification (commercial equivalent available)



Performance Characteristics

· Optical insertion loss:

·                  9/125 SM fiber: 0.25 dB avg.

·                  62.5/125 MM fiber: 0.6 dB avg.

· Operating temperature: -28°C to +65°C

· Vibration: per TIA/EIA-455-11, Condition II & VII

· Shock: MIL-S-901, GR.A, CL.1, high impact

· Mating durability: 500 cycles



M28876 Fiber Optic Cable Assembly common types:

· 28876 Breakout / Fan-out assemblies

· 28876 MQJ (Measurement Quality Jumper) For testing and certifying assemblies

· 28876 Hybrid Cable assemblies, with both Single mode and Multimode in the same cable

· 28876 Composite assemblies, with both fiber optic and electrical in the same assembly

· Single Mode 9/125µm M29504 Mil Termini, with either Pins or Sockets

· Multimode 62.5/125µm M29504 Termini, with either Pins or Sockets

· Multimode 50/125µm M29504 Termini, with either Pins or Sockets

· Multimode 100/140µm M29504 Termini, with either Pins or Sockets

Flowchart: Alternate Process: Fiber Optic Cables
Fiber Optic Cables

Toll Free (877)-320-3143

Call  (321)-473-8933

For Fiber Optic Cables and a fiber optic distribution companyUSA manufactured Fiber Optic CablesRoHS Compliant Fiber Optic CablesFiber Optic Cables
FibertronicsFiber Optic GSA Contract supplierFlowchart: Alternate Process: Fiber Optic Cables





MIL-C-28876

2, 4, 6, 8, 18, and 31 channel configurations

11, 13, 15, and 23 shell sizes

Singlemode, Multimode 62.5/125, Multimode 50/125, Multimode 100/140

Hybrid (Multimode and Singlemode) and Composite (Electro-optical)

Jam Nut, Wall Mount, or Plug

Straight, 90°, 45°, or no Backshell options
